5tr air cooled chiller
195000.0 INR/Piece
Product Details:
- Refrigerating Capacity 5 Ton (17.5 kW)
- Motor 1.5 HP
- Air Flow 1500 CFM
- Material Other
- Application Industrial and commercial water cooling
- Condition New
- Type Air Cooled Chiller
- Click to View more
X
5tr air cooled chiller Price And Quantity
- 1 Piece
- 195000.0 INR/Piece
5tr air cooled chiller Product Specifications
- 1.5 HP
- Brass
- 1500 CFM
- High efficiency hermetic scroll type
- Low noise design, less than 70 dB(A)
- Other
- 1.5 m3/hr
- 1.5 HP centrifugal pump
- Industrial and commercial water cooling
- 415 V
- New
- 3 Phase, 50 Hz
- Air Cooled Chiller
- Air Cooled
- 1150 x 750 x 1250 mm
- 5 Ton (17.5 kW)
- Copper with Aluminium fins
- Axial type, 1 HP
- Microprocessor-based digital controller
- Approx. 320 kg
- Outdoor/Indoor
- R407C / R410A / R22 (as per customer requirement)
- Overload protector, high/low pressure switch, antifreeze thermostat, phase failure relay
- Shell & Tube / Brazed Plate
- 7C to 25C (adjustable)
- 18-20 meters
- Thermostatic
- Up to 48C
- 5 TR
- Floor standing
- RAL 7035 Light Grey
Product Description
An air-cooled water chiller is a refrigeration system that removes heat from industrial or commercial processes and transfers it into the surrounding ambient air. It works by circulating chilled water or a water-glycol mixture to absorb heat, then expelling that heat outdoors using fans and condenser coils. [1, 2, 3, 4]Efficient Cooling Performance
With a 5 Ton (17.5 kW) capacity and a water flowing rate of 1.5 m3/hr, this air-cooled chiller delivers optimal cooling for demanding industrial and commercial setups. The shell & tube or brazed plate evaporator ensures effective heat exchange, while the axial-type condenser fan enhances air movement and consistent operation.
Advanced Digital Controls for Reliability
A microprocessor-based digital control panel provides precise temperature adjustments within a 7C to 25C range, ensuring operational consistency. The system incorporates vital safety features such as overload protection, antifreeze thermostat, and high/low-pressure switches, guaranteeing dependable performance in temperatures up to 48C ambient.
Robust Construction and Flexible Installation
Engineered from mild steel with a powder-coated finish, the unit is designed for longevity and resistance to harsh conditions. The mounting is floor standing, supporting stable installation both indoors and outdoors. Low operational noise-below 70 dB(A)-further enhances usability in diverse environments.
FAQ's of 5tr air cooled chiller:
Q: How does the 5TR air-cooled chiller maintain cooling efficiency in high ambient temperatures?
A: The chiller is equipped with a high efficiency hermetic scroll compressor and an axial-type condenser fan, enabling effective operation in ambient temperatures up to 48C. Its robust design and advanced controls ensure consistent cooling even under demanding conditions.Q: What is the process for installing this air-cooled chiller?
A: This chiller is designed for straightforward floor mounting and can be installed indoors or outdoors. It requires a stable, level surface and access to a three-phase, 415V, 50Hz power supply. Professional installation is recommended to ensure correct setup and safety compliance.Q: When should I select R407C, R410A, or R22 as the refrigerant?
A: The choice of refrigerant depends on regulatory requirements, energy efficiency goals, and specific application needs. R407C and R410A offer better environmental profiles and efficiency, while R22 may be specified for legacy systems. Selection should be made during the order process based on your operational criteria.Q: Where can the 5TR chiller be used effectively?
A: This chiller is ideal for industrial and commercial water cooling applications, such as process cooling, HVAC, and equipment temperature management. Its low-noise operation and compact size make it suitable for factories, labs, and office buildings.Q: What are the main safety features included in this chiller?
A: The unit incorporates multiple safety mechanisms such as overload protection, high/low pressure switches, antifreeze thermostat, and a phase failure relay. These features protect both the chiller and connected systems from electrical and mechanical faults.Q: How does the microprocessor-based digital controller benefit daily operation?
A: The advanced controller allows for precise temperature adjustment and system monitoring, improving efficiency and reliability. Users can easily set desired cooling parameters and receive alerts for any operational faults, resulting in easier maintenance and smoother performance.Tell us about your requirement
